The characteristics of Rexroth 4WE hydraulic valve can be summarized in four points:
1. Directional control versatility: These valves can flexibly control the flow direction of hydraulic oil within the system.
2. Reliable Performance: Rexroth 4WE valves are known for their consistent, reliable operation, ensuring smooth functionality.
3. Modular design: Rexroth 4WE directional control hydraulic valve adopts a modular structure and can be easily integrated into various hydraulic systems, enhancing adaptability and easy maintenance.
4. Wide range of configurations: These valves are available in a variety of sizes, pressure levels and spool configurations to meet different application requirements accurately and efficiently.
4WE series directional control valves are solenoid operated directionalspool valves, these valves are used to the start, stop and direct oil flow.
| Model | 4WE3 | 4WE4 | 4WE5 | 4WE6 | 4WE10 | |
| Max.flow rate(l/min) | 15 | 20 | 14 | 60 | 100 | |
| Working press ure(mpa) | A,B,P port
31.5 |
A,B,P port
31.5 |
A,B,P port
25 |
A,B,P port
31.5 |
A,B,P port
31.5 |
|
| T POT 10 | T POT 10 | T POT 6 | T POT 16 | T POT 16 | ||
| Weight
(kgs) |
Single solenoid | 0.55 | 0.83 | 1 | 1.5 | 4.8 |
| double solenoid | 0.7 | 1.1 | 1.4 | 2.2 | 6.1 | |

The characteristics of Rexroth 4WE hydraulic valve can be summarized in four points:
1. Directional control versatility: These valves can flexibly control the flow direction of hydraulic oil within the system.
2. Reliable Performance: Rexroth 4WE valves are known for their consistent, reliable operation, ensuring smooth functionality.
3. Modular design: Rexroth 4WE directional control hydraulic valve adopts a modular structure and can be easily integrated into various hydraulic systems, enhancing adaptability and easy maintenance.
4. Wide range of configurations: These valves are available in a variety of sizes, pressure levels and spool configurations to meet different application requirements accurately and efficiently.
4WE series directional control valves are solenoid operated directionalspool valves, these valves are used to the start, stop and direct oil flow.
| Model | 4WE3 | 4WE4 | 4WE5 | 4WE6 | 4WE10 | |
| Max.flow rate(l/min) | 15 | 20 | 14 | 60 | 100 | |
| Working press ure(mpa) | A,B,P port
31.5 |
A,B,P port
31.5 |
A,B,P port
25 |
A,B,P port
31.5 |
A,B,P port
31.5 |
|
| T POT 10 | T POT 10 | T POT 6 | T POT 16 | T POT 16 | ||
| Weight
(kgs) |
Single solenoid | 0.55 | 0.83 | 1 | 1.5 | 4.8 |
| double solenoid | 0.7 | 1.1 | 1.4 | 2.2 | 6.1 | |
 Â
POOCCA Hydraulics is a powerful hydraulic enterprise integrating R&D, manufacturing, sales and maintenance. Its products are exported to more than 120 countries. Its quality, price and service are deeply recognized and trusted by customers.
