The P120 series is an economical integrated directional valve with a wide range of uses. It has the characteristics of compact structure, stable performance, low price and strong versatility.
Control mode: manual, cable, electromagnetic, pneumatic, electro-hydraulic, etc.
4-spool manually operated valve with compact design suitable for installation in confined areas
All spools are standard double acting with spring return to center position ideal for double acting cylinders
For open center systems (flow from pump to tank) – closed center option available
P120 Hydraulic Manually Operated Valve Anti-drop Load Inspection on Each Spool
Precision ground and hard chrome plated valve core ensures longer service life
High-strength cast iron overall structure
SAE O-ring ports ensure a secure seal and prevent clogging
Vertical or horizontal handle installation
Adjustable pressure relief valve range: 1500 to 3625 PSI
Preset relief pressure: 2,610 PSI
| ORDER
CODE |
VALVE
TYPE |
NUMBER OF
SECTIONS |
NOMINAL FLOW
(lpm) |
MAX OPERATING
PRESSURES (bar) |
A
(mm) |
B
(mm) |
C
(mm) |
PORT SIZES
(bsp) |
|||||
| P | T | A – B | P | T | A – B | N | |||||||
| P1201A1G | P120 | 1 | 120 | 250 | 50 | 300 | 129 | 160 | 64 | 1” | 1” | 1” | – |
| P1202A1G | 2 | 182 | 213 | ||||||||||
| P1203A1G | 3 | 235 | 266 | ||||||||||
| P1204A1G | 4 | 288 | 319 | ||||||||||
Maximum operating pressure: P = 3625 PSI, T = 725 PSI, A and B = 4350 PSI
Rated flow: 31 GPM (117.35 L/min)
A and B Work Ports: #16 SAE O-ring (1 5⁄16 – 12) Thread
Inlet Port: #16 SAE O-ring (1 5⁄16 – 12) threaded
Outlet Port: #16 SAE O-ring (1 5⁄16 – 12) threaded
N-Port: #16 SAE O-ring (1 5⁄16 – 12) thread
3 – 5/16” mounting holes
POOCCA hydraulic manufacturer sells P40 P80 P120 hydraulic valves. If they are in stock, welcome to send your requirements and we will reply to you as soon as possible. To provide you with high-quality hydraulic products at discounted prices.
The primary application of hydraulic valves is to control and regulate fluid flow within hydraulic systems. P40 P80 P120 valves are used in various industries including manufacturing, construction, agriculture, aerospace and automotive. They play a vital role in controlling the direction, pressure and flow of hydraulic fluid to efficiently and safely power machinery and equipment.
4-spool manually operated valve with compact design suitable for installation in confined areas
All spools are standard double acting with spring return to center position ideal for double acting cylinders
For open center systems (flow from pump to tank) – closed center option available
P120 Hydraulic Manually Operated Valve Anti-drop Load Inspection on Each Spool
Precision ground and hard chrome plated valve core ensures longer service life
High-strength cast iron overall structure
SAE O-ring ports ensure a secure seal and prevent clogging
Vertical or horizontal handle installation
Adjustable pressure relief valve range: 1500 to 3625 PSI
Preset relief pressure: 2,610 PSI
| ORDER
CODE |
VALVE
TYPE |
NUMBER OF
SECTIONS |
NOMINAL FLOW
(lpm) |
MAX OPERATING
PRESSURES (bar) |
A
(mm) |
B
(mm) |
C
(mm) |
PORT SIZES
(bsp) |
|||||
| P | T | A – B | P | T | A – B | N | |||||||
| P1201A1G | P120 | 1 | 120 | 250 | 50 | 300 | 129 | 160 | 64 | 1” | 1” | 1” | – |
| P1202A1G | 2 | 182 | 213 | ||||||||||
| P1203A1G | 3 | 235 | 266 | ||||||||||
| P1204A1G | 4 | 288 | 319 | ||||||||||
Maximum operating pressure: P = 3625 PSI, T = 725 PSI, A and B = 4350 PSI
Rated flow: 31 GPM (117.35 L/min)
A and B Work Ports: #16 SAE O-ring (1 5⁄16 – 12) Thread
Inlet Port: #16 SAE O-ring (1 5⁄16 – 12) threaded
Outlet Port: #16 SAE O-ring (1 5⁄16 – 12) threaded
N-Port: #16 SAE O-ring (1 5⁄16 – 12) thread
3 – 5/16” mounting holes
POOCCA hydraulic manufacturer sells P40 P80 P120 hydraulic valves. If they are in stock, welcome to send your requirements and we will reply to you as soon as possible. To provide you with high-quality hydraulic products at discounted prices.
The primary application of hydraulic valves is to control and regulate fluid flow within hydraulic systems. P40 P80 P120 valves are used in various industries including manufacturing, construction, agriculture, aerospace and automotive. They play a vital role in controlling the direction, pressure and flow of hydraulic fluid to efficiently and safely power machinery and equipment.
POOCCA Hydraulics is a powerful hydraulic enterprise integrating R&D, manufacturing, sales and maintenance. Its products are exported to more than 120 countries. Its quality, price and service are deeply recognized and trusted by customers.
