The Yuken vane pump, characterized by the integration of two PV2R series single pumps in tandem within a unified housing, shares a common shaft for operation. This design features a single suction port and two discharge ports, enabling the distribution of output flow to distinct circuits. The efficiency and versatility of this configuration make Yuken vane pumps a reliable choice for applications requiring dual pump functionality in a compact design.
| F- | PV2R13 | -6 | -76 | -L | -R | A | A | A | -40 |
| Special Seals | Series Number | Small Volume Pump Nominal Displacement | Large Volume Pump Nominal Displacement | Mounting | Direction of   Rotation | Small Volume Pump Discharge Port Position | Large Volume Pump Discharge Port Position | Suction Port Position | Design Number |
| cm3/rev | cm3/rev | ||||||||
| F: Special seals for phosphate ester type fluids (Omit if notrequired) | PV2R12 | 6, 8 | 26 ,33 41, 47 53 ,59 65 |
L: Foot Mtg. F: Flange Mtg. |
R: Clockwise (Normal) |
E: Left 45° Upwards (Normal) |
A:Upwards (Normal) | A:Upwards (Normal) | 42 |
| 10 ,12 | |||||||||
| 14, 17 | |||||||||
| 19, 23 | |||||||||
| 25, 31 | |||||||||
| PV2R13 | 6, 8 | 76 ,94 116 |
A: Upwards (Normal) |
||||||
| 10, 12 | |||||||||
| 14 ,17 | |||||||||
| 19, 23 | |||||||||
| 25, 31 | |||||||||
| PV2R23 | 41, 47 | 52, 60 66 ,76 94 ,116 |
E:Left 45° Upwards (Normal) | 41 | |||||
| 53 ,59 | |||||||||
| 65 | |||||||||
| PV2R33 | 76 ,94 | 76 ,94 116 |
A:Upwards (Normal) | 31 | |||||
| 116 | |||||||||
| PV2R14 | 6 ,8 | 136, 153 184, 200 237 |
A: Upwards (Normal) |
32 | |||||
| 10, 12 | |||||||||
| 14 ,17 | |||||||||
| 19 ,23 | |||||||||
| 25 31 | |||||||||
| PV2R24 | 26 ,33 | 31 | |||||||
| 41, 47 | |||||||||
| 52 ,60 | |||||||||
| PV2R34 | 66, 76 | E:Left 45° Upwards (Normal) | |||||||
| 94 ,116 |
Yuken PV2R Hydraulic Double Vane Pump:PV2R12,PV2R13,PV2R23,PV2R33,PV2R14,PV2R24,PV2R34
The Yuken vane pump, characterized by the integration of two PV2R series single pumps in tandem within a unified housing, shares a common shaft for operation. This design features a single suction port and two discharge ports, enabling the distribution of output flow to distinct circuits. The efficiency and versatility of this configuration make Yuken vane pumps a reliable choice for applications requiring dual pump functionality in a compact design.
| F- | PV2R13 | -6 | -76 | -L | -R | A | A | A | -40 |
| Special Seals | Series Number | Small Volume Pump Nominal Displacement | Large Volume Pump Nominal Displacement | Mounting | Direction of   Rotation | Small Volume Pump Discharge Port Position | Large Volume Pump Discharge Port Position | Suction Port Position | Design Number |
| cm3/rev | cm3/rev | ||||||||
| F: Special seals for phosphate ester type fluids (Omit if notrequired) | PV2R12 | 6, 8 | 26 ,33 41, 47 53 ,59 65 |
L: Foot Mtg. F: Flange Mtg. |
R: Clockwise (Normal) |
E: Left 45° Upwards (Normal) |
A:Upwards (Normal) | A:Upwards (Normal) | 42 |
| 10 ,12 | |||||||||
| 14, 17 | |||||||||
| 19, 23 | |||||||||
| 25, 31 | |||||||||
| PV2R13 | 6, 8 | 76 ,94 116 |
A: Upwards (Normal) |
||||||
| 10, 12 | |||||||||
| 14 ,17 | |||||||||
| 19, 23 | |||||||||
| 25, 31 | |||||||||
| PV2R23 | 41, 47 | 52, 60 66 ,76 94 ,116 |
E:Left 45° Upwards (Normal) | 41 | |||||
| 53 ,59 | |||||||||
| 65 | |||||||||
| PV2R33 | 76 ,94 | 76 ,94 116 |
A:Upwards (Normal) | 31 | |||||
| 116 | |||||||||
| PV2R14 | 6 ,8 | 136, 153 184, 200 237 |
A: Upwards (Normal) |
32 | |||||
| 10, 12 | |||||||||
| 14 ,17 | |||||||||
| 19 ,23 | |||||||||
| 25 31 | |||||||||
| PV2R24 | 26 ,33 | 31 | |||||||
| 41, 47 | |||||||||
| 52 ,60 | |||||||||
| PV2R34 | 66, 76 | E:Left 45° Upwards (Normal) | |||||||
| 94 ,116 |
Yuken PV2R Hydraulic Double Vane Pump:PV2R12,PV2R13,PV2R23,PV2R33,PV2R14,PV2R24,PV2R34
