Structure:
Eaton Vickers VQ Vane Pump The oil flow rate in all pumps is
Formed in the movement, the movement mainly includes the stator, rotor,
Ten blades and unique side and support plates. bimetalflexible
Side plates are located on each side of the rotor, with their bronze sides facing the rotor.
Its steel surface faces the support plate. Two cavities in each support plate
Maintain high-pressure oil to act on the flexible side plates to achieve flexible side plates
Hydraulic balance and ensure optimal clearance with the rotor.
Performance:
Due to maximum power and size, high efficiency, maintainability and economy
combination of features, Vickers’ “high output” pumps are used throughout industry
is unique.
Durability:
Vickers high speed and high pressure pumps give greater durability. it
Being able to do hard work is already found in the latest giant earthmoving equipment.
Bei Shang confirmed.
reliability and efficiency:
Axial and radial working clearances, as well as on rotors and blades.The lubricant film of the VQ Vane Pump is optimal throughout the entire operating pressure range. Outstanding cold starting ability and high seizure resistance properties make Vickers VQ pumps highly reliable and efficient.
| Single Pump VQ pump | Delivery Us gpm @ 1200 r/min 7 bar (100 psi) |
Displacement cm3/r (in3/r) |
Max. r/min |
Max. bar (psi) |
Typical del. L/min (US gpm) @ max. speed & pressure |
Typical input kW(hp) @ max. speed & pressure |
Weight kg (lb) |
| 20VQ | 5 | 18,0 (1.10) | 2700 | 210 (3000) | 42,3 (11) | 17,9 (24) | 11,8 (26) |
| 8 | 27,4 (1.67) | 2700 | 210 (3000) | 65,4 (17) | 26,1 (35) | ||
| 11 | 36,4 (2.22) | 2700 | 210 (3000) | 88,5 (23) | 35,4 (47.5) | ||
| 12 | 39,5 (2.41) | 2700 | 160 (2300) | 98,1 (25.5) | 28,4 (38) | ||
| 14 | 45,9 (2.80) | 2700 | 140 (2000) | 115,4 (30) | 29,1 (39) | ||
| 25VQ | 12 | 40,2 (2.45) | 2700 | 210 (3000) | 88,5 (23) | 41,0 (55) | 14,5 (32) |
| 14 | 45,4 (2.77) | 2700 | 210 (3000) | 103,8 (27) | 46,6 (62.5) | ||
| 17 | 55,2 (3.37) | 2500 | 210 (3000) | 119,2 (31) | 51,8 (69.5) | ||
| 21 | 67,5 (4.12) | 2500 | 210 (3000) | 146,2 (38) | 61,9 (83) | ||
| 35VQ | 25 | 81,6 (4.98) | 2500 | 210 (3000) | 173,1 (45) | 75,3 (101) | 22,7 (50) |
| 30 | 97,7 (5.96) | 2500 | 210 (3000) | 211,5 (55) | 87,7 (117.5) | ||
| 35 | 112,8 (6.88) | 2400 | 210 (3000) | 230,8 (60) | 98,5 (132) | ||
| 38 | 121,6 (7.42) | 2400 | 210 (3000) | 250,0 (65) | 104,4 (140) | ||
| 45VQ | 42 | 138,7 (8.46) | 2200 | 175 (2500) | 255,8 (66.5) | 91,4 (122.5) | 34,1 (75) |
| 50 | 162,3 (9.90) | 2200 | 175 (2500) | 303,8 (79) | 105,2 (141) | ||
| 60 | 193,4 (11.80) | 2200 | 175 (2500) | 369,2 (96) | 126,8 (170) |
