For applications involving high pressures and long periods of continuous operation, we at Poocca Hydraulics specifically recommend the efficient and high-performance Hyva type piston pumps. Its unique curved shaft design not only makes it compact in appearance, but also significantly reduces operating noise. This series of pumps underwent rigorous durability testing during the development phase, including laboratory and field tests simulating 100,000 tipping cycles, to ensure its usability.
Key features include:
High Pressure Capacity: Designed for working pressures up to 350 bar, ideal for systems requiring high intensity and long-term continuous operation.
Low-noise design: Hyva hydraulic piston pump curved shaft technology makes the pump less noisy during operation, reducing sound pollution from the equipment.
Durable: The pump’s bearing design can withstand extremely high radial and thrust loads, ensuring its long life in various harsh environments and minimizing downtime.
Diverse choices: In addition to single-flow pumps, Hyva also offers dual-flow pumps, especially suitable for applications with complex needs such as scrap and timber cranes.
One of our best-selling products is the 4H series piston pump with curved shaft design, which is widely used in high-pressure and continuous working situations to meet the diverse needs of different customers.
| Part no. | Description | Displacement (cm³/rev) | Working
pressure (bar) |
Rotation
frequency (rpm) |
Pressure port | Weight (kg) | Rotation |
| 14535155 | PISTON PUMP F1-025L-L-4H | 25.60 | 350 | 2200 | G3⁄4 | 8.5 | Left |
| 14535160 | PISTON PUMP F1-025L-R-4H | 25.60 | 350 | 2200 | G3⁄4 | 8.5 | Right |
| 14535165 | PISTON PUMP F1-041L-L-4H | 40.90 | 350 | 2100 | G3⁄4 | 8.5 | Left |
| 14535170 | PISTON PUMP F1-041L-R-4H | 40.90 | 350 | 2100 | G3⁄4 | 8.5 | Right |
| 14535175 | PISTON PUMP F1-051L-L-4H | 51.10 | 350 | 1900 | G3⁄4 | 8.5 | Left |
| 14535180 | PISTON PUMP F1-051L-R-4H | 51.10 | 350 | 1900 | G3⁄4 | 8.5 | Right |
| 14535185 | PISTON PUMP F1-061L-L-4H | 59.50 | 350 | 1900 | G3⁄4 | 8.5 | Left |
| 14535190 | PISTON PUMP F1-061L-R-4H | 59.50 | 350 | 1900 | G3⁄4 | 8.5 | Right |
| 14535120 | PISTON PUMP T1-081L-L-4H | 81.50 | 250 | NA | G3⁄4 | 12.5 | Left |
| 14535119 | PISTON PUMP T1-081L-R-4H | 81.50 | 250 | NA | G3⁄4 | 12.5 | Right |
At Poocca, customization is at the heart of what we do. From custom model specifications to personalized logos and packaging, we offer a full range of customization options to meet your unique needs. Our team of professionals work closely with you to experience Poocca customization.
Poocca is a leading hydraulic manufacturer with over 20 years of industry expertise. With stable partnerships in multiple countries, we have won unanimous praise for our competitive prices and excellent quality. Our commitment to excellence ensures customers around the world trust us to meet their hydraulic needs. Whether it’s reliability, performance or innovation, Poocca delivers reliable solutions that exceed expectations. Choose Poocca for hydraulic solutions you can trust.
For applications involving high pressures and long periods of continuous operation, we at Poocca Hydraulics specifically recommend the efficient and high-performance Hyva type piston pumps. Its unique curved shaft design not only makes it compact in appearance, but also significantly reduces operating noise. This series of pumps underwent rigorous durability testing during the development phase, including laboratory and field tests simulating 100,000 tipping cycles, to ensure its usability.
Key features include:
High Pressure Capacity: Designed for working pressures up to 350 bar, ideal for systems requiring high intensity and long-term continuous operation.
Low-noise design: Hyva hydraulic piston pump curved shaft technology makes the pump less noisy during operation, reducing sound pollution from the equipment.
Durable: The pump’s bearing design can withstand extremely high radial and thrust loads, ensuring its long life in various harsh environments and minimizing downtime.
Diverse choices: In addition to single-flow pumps, Hyva also offers dual-flow pumps, especially suitable for applications with complex needs such as scrap and timber cranes.
One of our best-selling products is the 4H series piston pump with curved shaft design, which is widely used in high-pressure and continuous working situations to meet the diverse needs of different customers.
| Part no. | Description | Displacement (cm³/rev) | Working
pressure (bar) |
Rotation
frequency (rpm) |
Pressure port | Weight (kg) | Rotation |
| 14535155 | PISTON PUMP F1-025L-L-4H | 25.60 | 350 | 2200 | G3⁄4 | 8.5 | Left |
| 14535160 | PISTON PUMP F1-025L-R-4H | 25.60 | 350 | 2200 | G3⁄4 | 8.5 | Right |
| 14535165 | PISTON PUMP F1-041L-L-4H | 40.90 | 350 | 2100 | G3⁄4 | 8.5 | Left |
| 14535170 | PISTON PUMP F1-041L-R-4H | 40.90 | 350 | 2100 | G3⁄4 | 8.5 | Right |
| 14535175 | PISTON PUMP F1-051L-L-4H | 51.10 | 350 | 1900 | G3⁄4 | 8.5 | Left |
| 14535180 | PISTON PUMP F1-051L-R-4H | 51.10 | 350 | 1900 | G3⁄4 | 8.5 | Right |
| 14535185 | PISTON PUMP F1-061L-L-4H | 59.50 | 350 | 1900 | G3⁄4 | 8.5 | Left |
| 14535190 | PISTON PUMP F1-061L-R-4H | 59.50 | 350 | 1900 | G3⁄4 | 8.5 | Right |
| 14535120 | PISTON PUMP T1-081L-L-4H | 81.50 | 250 | NA | G3⁄4 | 12.5 | Left |
| 14535119 | PISTON PUMP T1-081L-R-4H | 81.50 | 250 | NA | G3⁄4 | 12.5 | Right |
At Poocca, customization is at the heart of what we do. From custom model specifications to personalized logos and packaging, we offer a full range of customization options to meet your unique needs. Our team of professionals work closely with you to experience Poocca customization.
Poocca is a leading hydraulic manufacturer with over 20 years of industry expertise. With stable partnerships in multiple countries, we have won unanimous praise for our competitive prices and excellent quality. Our commitment to excellence ensures customers around the world trust us to meet their hydraulic needs. Whether it’s reliability, performance or innovation, Poocca delivers reliable solutions that exceed expectations. Choose Poocca for hydraulic solutions you can trust.
