This series of gear pumps is an external meshing volumetric pump
Flow range: 2.5-160L/min
CB-B2.5,CB-B4,CB-B6,CB-B10,CB-B16,CB-B20,CB-B25,CB-B32,CB-B40,CB-B50,CB-B63,CB-B80,CB-B100,CB-B125,CB-B160
For more direct sales of hydraulic gear pumps from Poocca factory, please contact us immediately for a quote.
**CB-B gear pump is a power element in hydraulic system.
**The pump adopts high-precision gears, high-strength cast iron housing and other structures. It is a conversion device that converts the mechanical energy transmitted by the motor into hydraulic energy through meshing gears.
**Provides fixed hydraulic energy in the hydraulic system.
**CB hydraulic gear pump has simple structure, reliable operation, convenient maintenance, good adaptability to impact loads, and is widely used in machine tool hydraulic systems and can be used in hydraulic systems of other machines.
|
Model |
Rated flow L/min |
Rate
d Pres -sure MPa |
Rate
d Spee d r/mi n |
Volumet
ric Efficienc y nv% |
Overall Efficienc y nt% |
Pressure Fluctuatio n MPa |
Noise db |
Power Driving kw |
Weigh kg |
| CB-B2.5 | 2.5 |
2.5 |
1450 |
≥70 | ≥63 |
±0.15 |
62～65 |
0.18 | 1.6 |
| CB-B4 | 4 | ≥80 | ≥72 | 0.21 | 1.7 | ||||
| CB-B6 | 6 | 0.31 | 1.8 | ||||||
| CB-B10 | 10 |
≥90 |
≥81 |
0.51 | 2.1 | ||||
| CB-B16 | 16 |
67～70 |
0.82 | 4.2 | |||||
| CB-B20 | 20 | 1.02 | 4.4 | ||||||
| CB-B25 | 25 | 1.3 | 4.6 | ||||||
| CB-B32 | 32 |
≥94 |
≥85 |
1.65 | 5 | ||||
| CB-B40 | 40 |
74～77 |
2.1 | 7.2 | |||||
| CB-B50 | 50 | 2.6 | 7.6 | ||||||
| CB-B63 | 63 | 3.3 | 7.8 | ||||||
| CB-B80 | 80 |
80～ 83 |
4.1 | 12.6 | |||||
| CB-B100 | 100 |
≥95 |
286 |
5.1 | 13.3 | ||||
| CB-B125 | 125 | 6.5 | 14.5 | ||||||
| CB-B160 | 160 | 8.2 | 15.6 |
CB series gear pumps have two types of tooth shapes: straight and helical, with meshing displacement outside. They are used to deliver mineral oil with a viscosity of 1 to 8°, hydraulic oil, mechanical oil, fuel oil, etc. with an oil temperature of 10℃~60℃.
CB-B series gear pumps are widely used in hydraulic systems such as machine tools, hydraulic machinery, and engineering machinery as power source systems. They can also be used for oil pumps, lubrication pumps, and fuel pumps in equipment such as thin oil stations, metallurgy, mining, petroleum, chemical industry, and textile machinery.
* Note: If the medium temperature is between 60℃~200℃, please indicate, Poocca gear pump manufacturer will tailor it for you according to your special requirements.
**CB-B gear pump is a power element in hydraulic system.
**The pump adopts high-precision gears, high-strength cast iron housing and other structures. It is a conversion device that converts the mechanical energy transmitted by the motor into hydraulic energy through meshing gears.
**Provides fixed hydraulic energy in the hydraulic system.
**CB hydraulic gear pump has simple structure, reliable operation, convenient maintenance, good adaptability to impact loads, and is widely used in machine tool hydraulic systems and can be used in hydraulic systems of other machines.
|
Model |
Rated flow L/min |
Rate
d Pres -sure MPa |
Rate
d Spee d r/mi n |
Volumet
ric Efficienc y nv% |
Overall Efficienc y nt% |
Pressure Fluctuatio n MPa |
Noise db |
Power Driving kw |
Weigh kg |
| CB-B2.5 | 2.5 |
2.5 |
1450 |
≥70 | ≥63 |
±0.15 |
62～65 |
0.18 | 1.6 |
| CB-B4 | 4 | ≥80 | ≥72 | 0.21 | 1.7 | ||||
| CB-B6 | 6 | 0.31 | 1.8 | ||||||
| CB-B10 | 10 |
≥90 |
≥81 |
0.51 | 2.1 | ||||
| CB-B16 | 16 |
67～70 |
0.82 | 4.2 | |||||
| CB-B20 | 20 | 1.02 | 4.4 | ||||||
| CB-B25 | 25 | 1.3 | 4.6 | ||||||
| CB-B32 | 32 |
≥94 |
≥85 |
1.65 | 5 | ||||
| CB-B40 | 40 |
74～77 |
2.1 | 7.2 | |||||
| CB-B50 | 50 | 2.6 | 7.6 | ||||||
| CB-B63 | 63 | 3.3 | 7.8 | ||||||
| CB-B80 | 80 |
80～ 83 |
4.1 | 12.6 | |||||
| CB-B100 | 100 |
≥95 |
286 |
5.1 | 13.3 | ||||
| CB-B125 | 125 | 6.5 | 14.5 | ||||||
| CB-B160 | 160 | 8.2 | 15.6 |
CB series gear pumps have two types of tooth shapes: straight and helical, with meshing displacement outside. They are used to deliver mineral oil with a viscosity of 1 to 8°, hydraulic oil, mechanical oil, fuel oil, etc. with an oil temperature of 10℃~60℃.
CB-B series gear pumps are widely used in hydraulic systems such as machine tools, hydraulic machinery, and engineering machinery as power source systems. They can also be used for oil pumps, lubrication pumps, and fuel pumps in equipment such as thin oil stations, metallurgy, mining, petroleum, chemical industry, and textile machinery.
* Note: If the medium temperature is between 60℃~200℃, please indicate, Poocca gear pump manufacturer will tailor it for you according to your special requirements.
