Up to 7 MPa (1020 PSI), 498 cm 3/rev (30.34 CU.IN./rev)
Yuken 50T 150T 250F vane pumps are widely used as hydraulic power sources. They combine stable performance and powerful building delivery rates in a wide range.
Model: 50T, 150T, 250F
Displacement: 6.8- 201.0 cm 3 /rev
Please send us your requirements and we will provide you with prices and relevant information immediately.
| Model Numbers | Geometric
Displacement cm 3 /rev (cu.in /rev) |
Maximum 1
Operating Pressure MPa (PSI) |
Output Flow
& Input Power |
Shaft Speed Range r/min | Approx. Mass
kg (lbs.) |
||
| Max. | Min. | Foot Mtg. | Flange Mtg. | ||||
| 50T-7 | 6.8 ( .415) |
7 (1020) |
Refer to Pages 7 & 8. |
2
2000 |
800 |
10.5 (23.2) |
9.0 (19.8) |
| 50T-12 | 11.6 ( .708) |
600 |
|||||
| 50T-17 | 16.5 ( 1.007) |
2 1800 |
|||||
| 50T-23 | 22.9 ( 1.397) | ||||||
| 50T-26 | 25.9 ( 1.580) | ||||||
| 50T-36 | 36.0 ( 2.20) | ||||||
| 150T-48 | 47.7 ( 2.91) |
7 (1020) |
Refer to Pages 8 & 9. |
2
1500 |
600 |
26 (57.3) |
25 (55.1) |
| 150T-61 | 61.1 ( 3.73) | ||||||
| 150T-75 | 74.9 ( 4.57) | ||||||
| 150T-94 | 93.6 ( 5.71) | 1200 | |||||
| 150T-116 | 115.6 ( 7.05) | ||||||
| 250F-134 | 133.9 ( 8.17) |
7 (1020) |
Refer to Page 10. |
1200 |
600 |
120 (265) |
113 (249) |
| 250F-153 | 153.1 ( 9.34) | ||||||
| 250F-176 | 175.8 (10.73) | ||||||
| 250F-200 | 201.0 (12.27) | ||||||
The 50T vane pump is a low-pressure, fixed-displacement hydraulic pump designed for applications requiring consistent flow in low-pressure segments of high/low pressure systems. It is commonly used in equipment such as grinders, hydraulic presses, die casting machines, rubber machinery, and various industrial machine tools.
Up to 7 MPa (1020 PSI), 498 cm 3/rev (30.34 CU.IN./rev)
Yuken 50T 150T 250F vane pumps are widely used as hydraulic power sources. They combine stable performance and powerful building delivery rates in a wide range.
Model: 50T, 150T, 250F
Displacement: 6.8- 201.0 cm 3 /rev
Please send us your requirements and we will provide you with prices and relevant information immediately.
| Model Numbers | Geometric
Displacement cm 3 /rev (cu.in /rev) |
Maximum 1
Operating Pressure MPa (PSI) |
Output Flow
& Input Power |
Shaft Speed Range r/min | Approx. Mass
kg (lbs.) |
||
| Max. | Min. | Foot Mtg. | Flange Mtg. | ||||
| 50T-7 | 6.8 ( .415) |
7 (1020) |
Refer to Pages 7 & 8. |
2
2000 |
800 |
10.5 (23.2) |
9.0 (19.8) |
| 50T-12 | 11.6 ( .708) |
600 |
|||||
| 50T-17 | 16.5 ( 1.007) |
2 1800 |
|||||
| 50T-23 | 22.9 ( 1.397) | ||||||
| 50T-26 | 25.9 ( 1.580) | ||||||
| 50T-36 | 36.0 ( 2.20) | ||||||
| 150T-48 | 47.7 ( 2.91) |
7 (1020) |
Refer to Pages 8 & 9. |
2
1500 |
600 |
26 (57.3) |
25 (55.1) |
| 150T-61 | 61.1 ( 3.73) | ||||||
| 150T-75 | 74.9 ( 4.57) | ||||||
| 150T-94 | 93.6 ( 5.71) | 1200 | |||||
| 150T-116 | 115.6 ( 7.05) | ||||||
| 250F-134 | 133.9 ( 8.17) |
7 (1020) |
Refer to Page 10. |
1200 |
600 |
120 (265) |
113 (249) |
| 250F-153 | 153.1 ( 9.34) | ||||||
| 250F-176 | 175.8 (10.73) | ||||||
| 250F-200 | 201.0 (12.27) | ||||||
The 50T vane pump is a low-pressure, fixed-displacement hydraulic pump designed for applications requiring consistent flow in low-pressure segments of high/low pressure systems. It is commonly used in equipment such as grinders, hydraulic presses, die casting machines, rubber machinery, and various industrial machine tools.
